AK1
PTZ Camera Controller

The bedside infotainment terminal is designed for the hospital and clinical environment. It integrates a computer, television, phone and nurse call button into a single, easy-to-use, touch-screen product that provides patients with entertainment, communication, self-service and education options. It‘s also capable of managing clinical records from the bedside in real time, visual control from the nursing station or communication and attention with doctors in wards, hospitals.

Cross protocol mix-control with IP/ RS-422/ RS-485/ RS-232
Control protocol by VISCA, VISCA-Over-IP, Onvif and Pelco P&D
Control up to total of 255 IP cameras on a single network
3 camera quick call up keys, or 3 user-assignable keys to quickly invoke shortcut functions
Quick control of exposure, shutter speed, iris, compensation, white balance, focus, pan/tilt speed, zoom speed
Tactile feel with professional rocker/seesaw switch for zoom control
Automatically search available IP cameras in a network and assign IP addresses easily
Multi-color key illumination indicator directs operation to specific functions
Tally GPIO output for indicating the camera be currently controlled
Metal housing with 2.2 inch LCD display, joystick, 5 rotation button
Supports both POE and 12V DC power supplies

Description

Specifications

Accessories

Download

Connection Diagram

Adopt RS-232, RS-422, RS-485 and IP(RJ45) multiple interface control signal, up to 255 cameras can be connected. The following connection diagram shows how to control multiple cameras through IP through the PTZ controller.

Application Fields

The controller can be widely used in various field events, such as education, business, interviews, concert, health care, teleconsultation and other live broadcast activities.

Specifications

CONNECTIONS	Interfaces	IP(RJ45), RS-232, RS-485/RS-422
	Control Protocol	IP Protocol: ONVIF, VISCA Over IP
	Control Protocol	Serial Protocol: PELCO-D, PELCO-P, VISCA
USER INTERFACES	Serial Baud Rate	2400, 4800, 9600, 19200, 38400 bps
	Display	2.2 inch LCD
	Joystick	Pan/Tilt/Zoom
	Camera shortcut	3 channels
	Keyboard	User-assignable keys×3, Lock×1, Menu×1, BLC×1, Rotation button×5,
	Keyboard	Rocker×1,Seesaw×1
	Camera Address	Up to 255
	Preset	Up to 255
POWER	Power	PoE/ DC 12V
POWER	Power Consumption	PoE: 5W, DC: 5W
ENVIRONMENT	Working Temperature	-20°C~60°C
ENVIRONMENT	Storage Temperature	-40°C~80°C
DIMENSION	Dimension(LWD)	270mm×145mm×29.5mm/ 270mm×145mm×106.6mm(With joystick)
DIMENSION	Weight	1181g
